- Drive Type: 12 Point
- Drive size: 1/2″
- Corrosion resistant black oxide finish.
- Made of premium tool steel and precision heat-treated for maximum durability.
- Hex openings deliver maximum turning power without rounding fasteners.
- Limited lifetime warranty.
- Meets ANSI standards.
| Part No. | Size | Overall Length (mm) | Drive End (mm) | Hex End (mm) | Taper Length (mm) | Bolt Clearance (mm) |
|---|---|---|---|---|---|---|
| MP10DH | 10mm | 38 | 24 | 17 | 16 | 8 |
| MP11DH | 11mm | 38 | 24 | 18 | 16 | 9 |
| MP12DH | 12mm | 38 | 24 | 19 | 16 | 10 |
| MP13DH | 13mm | 38 | 24 | 20 | 16 | 11 |
| MP14DH | 14mm | 38 | 24 | 22 | 16 | 12 |
| MP15DH | 15mm | 38 | 24 | 24 | – | 13 |
| MP16DH | 16mm | 38 | 24 | 24 | – | 14 |
| MP17DH | 17mm | 38 | 26 | 26 | – | 15 |
| MP18DH | 18mm | 38 | 26 | 26 | – | 16 |
| MP19DH | 19mm | 38 | 28 | 28 | – | 17 |
| MP20DH | 20mm | 38 | 30 | 30 | – | 18 |
| MP21DH | 21mm | 38 | 30 | 30 | – | 19 |
| MP22DH | 22mm | 38 | 32 | 32 | – | 20 |
| MP23DH | 23mm | 38 | 32 | 32 | – | 21 |
| MP24DH | 24mm | 45 | 34 | 34 | – | 22 |
| MP30DH | 30mm | 50 | 38 | 42 | – | 28 |
| MP32DH | 32mm | 50 | 38 | 44 | – | 30 |
